Vortex流量计放大器参数设置参考表：
cal DN | 液体 | 气体 | ||||||||
GB. | SB. | K1-ON. | K2-ON. | K3-ON. | GB. | SB. | K1-ON. | K2-ON. | K3-ON. | |
15 | 3 | 3 | 1,3,5,7. | 5 | 3 | 3 | 3 | 1,2,5,6. | 1 | 1 |
20 | 3 | 3 | 1,3,5,7. | 5 | 3 | 3 | 3 | 1,2,5,6. | 1 | 1 |
25 | 3 | 3 | 1,3,5,7. | 4 | 4 | 3 | 1,3 | 1,2,5,6. | 1 | 1 |
40 | 1 | 3 | 4,8 | 8 | 4 | 2 | 3 | 1,3,5,7. | 2 | 2 |
50 | 1 | 3 | 4,8 | 8 | 4 | 2 | 3 | 1,3,5,7. | 2 | 3 |
65 | 1 | 3 | 4,8 | 8 | 4 | 2 | 3 | 1,3,5,7. | 2 | 3 |
80 | 1 | 3 | 4,8 | 8 | 5 | 2 | 3 | 1,3,5,7. | 3 | 1,3 |
100 | 1 | 3 | 4,8 | 8 | 5 | 2 | 3 | 1,3,5,7. | 3 | 1,3 |
125 | 1 | 3 | 2,4,6,8.8 | 8 | 6 | 1,3 | 1,3 | 3,7. | 4 | 2,3 |
150 | 2 | 3 | 2,4,6,8.8 | 8 | 4,6 | 1,3 | 1,3 | 3,7. | 4 | 4 |
200 | 3 | 3 | 2,4,6,8.8 | 8 | 4,5,6. | 2,3 | 2,3 | 4,8 | 5 | 4 |
250 | 3 | 3 | 3,4,7,8. | 8 | 4,5,6. | 2,3 | 2,3 | 4,8 | 6 | 4 |
300 | 3 | 3 | 3,4,7,8. | 8 | 7 | 2,3 | 2,3 | 4,8 | 6 | 5 |
